Compact and versatile the PB Series is ideal for a wide range of commercial power and data applications.
Power entry and exit can be achieved by hardwired power cord and/or Wieland GST18 connectors.
The PB Series can mounted directly to a screen and comes in black as standard with other colours available on request and subject to minimum order quantities.
The PB Series can be configured with Australian or international power sockets, Data/AV connectivity, and our class leading TUF-R USB fast mobile and tablet charger or TUF-R HP (high powered) USB C fast mobile, tablet and laptop charger.
TUF-R is quick and simple to replace without the need to turn off the power or call an electrician. The unique and patented benefit of being replaceable makes TUF-R perfect for areas of high traffic, such as public spaces, education, and hospitality, where if damaged through misuse, TUF-R can quickly be replaced. Replacing or upgrading the TUF-R module and not the whole product saves time, resources, and reduces waste.
Click to see how quick the TUF-R USB charging module is to replace
OE Elsafe has introduced the world’s first reversible Type-A port, enabling a first-time connection every time. Connectors can be inserted both ways, cutting down on wear and damage from unsuccessful attempts and extending the life of the module and the product it is fitted into.
Data transfer is not possible as TUF-R has no external data connections or the ability to store enough code to put malware on a device.
Configuration |
The PB Series is available in 2, 3 and 4 gang units that can be configured with a combination of power, data/AV and USB charging including our class leading TUF-R USB mobile and tablet or TUF-R HP USB mobile, tablet and laptop charger. |
Construction |
The PB SERIES body mouldings are constructed from fire retardant ABS, socket fascias are moulded from fire retardant polycarbonate. |
Size Options |
2 Gang 3 Gang 4 Gang |
Colour Options |
Main body – black Socket fascia – black as standard (other colours are available) Cable/wieland connectors – black |
Power Connection Options |
Male GST input and female GST output for cascading Hardwired leads with J Coupler or Wieland GST connections |
Quality and Testing |
Visual: Configuration and appearance. Power sockets: Continuity, polarity, insulation and earth USB charger: Output voltage and resistance All sockets continuity tested with batch performance testing “We test every pin on every connection in every socket” |
